Attach width units to main beam 8.975″ from either end. Leg 7-5/8″ from left end control box 7-5/8″ from right end. The following procedure is for the 44″ and 58″ Destackers Attach leg and control box to main beam. Attach width units to main beam, 4-3/8″ from either end square to main beam and Parallel to each other.Ĥ. Control box should be 3″ from right side of main beam. Leg should be flush to left side of main beam. The following procedure is for a 29″ Destacker. Pull the latest Electrical and Mechanical prints.ģ. Pull all parts if any parts are missing, fill out a shortage sheet and give a copy to the appropriate material coordinator.Ģ. Obtain the proper shop packet and check order for build information.
